Vertical Rope Climbing Net – Trim Trail Element
Tapered rope climbing net on angled galvanised steel posts. A climb-over trim trail element for up to 5 users aged 4–14, BS EN 1176 certified.
Overview
A tapered rope climbing net strung between angled steel posts. Children climb up one side, cross the top rope and climb down the other, building grip, upper-body strength and confidence at height. It adds a climbing section to a school or park trim trail and links easily with bridges, traverses and balance elements. The 3.36 m span takes up to 5 children at once. Galvanised, powder-coated steel posts carry steel-core rope with plastic, stainless steel or aluminium connectors and calibrated stainless steel chains, built for busy public sites. Certified to BS EN 1176-1 for ages 4–14.
- Product type: Vertical rope climbing net, trim trail element
- Functions: Climbing, pull-up and grip, balance, passage, upper-body strength, coordination
- Dimensions (L x W x H): 3.36 x 0.11 x 2.23 m
- Safety zone: 7.16 x 3.91 m (24.9 m²)
- Free-fall height: 2.0 m
- User capacity: 5
- Users: Recommended age 4–14
- Frame: 100 × 100 mm steel posts, hot-dip galvanised and powder-coated (or powder-galvanised and powder-coated)
- Ropes: Steel-core ropes in polypropylene braid with plastic, stainless steel or aluminium connectors
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Fixings: Stainless steel screws or screws under plastic caps; polypropylene end caps
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: EN 1177 impact-absorbing surfacing across the impact area, rated to at least 2.0 m
- Morti ref.: MSP1607JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
.webp)
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
