Adventure Climbing Frame with Monkey Bars, Rope Nets & Climbing Wall
Steel adventure climbing frame with monkey bars, rope nets, rope ladder and climbing wall for 17 users aged 3–14. BS EN 1176. For schools and parks.
Overview
A long, linear climbing frame that links its activities into one adventure route. Children scale a curved climbing wall, cross a vertical rope net, swing hand over hand along the overhead monkey bars and finish on a rope ladder and angled scramble net, building grip, upper-body strength, balance and route planning as they go. With room for 17 users at once, it suits busy KS1 and KS2 playgrounds, parks and housing development play areas. The galvanised, powder-coated 80 mm steel frame carries HPL panels, resin climbing holds and steel-core rope, and the unit is certified to BS EN 1176-1. Designed, supplied and installed by Morti Sport & Play.
- Product type: Steel climbing frame with monkey bars, rope nets and climbing wall
- Play activities: Climbing wall (curved HPL wall with resin holds); Rope net (vertical net climb between the posts); Monkey bars (overhead stainless steel ladder, hand over hand); Rope ladder (flexible ladder with synthetic rungs); Angled net (a gentler scramble climb at the far end); Pull-up bars (steel bars for hanging and pulling up)
- Dimensions (L x W x H): 4.53 x 1.87 x 2.41 m
- Safety zone: 8.33 x 5.67 m (39.0 m²)
- Free-fall height: 2.25 m
- User capacity: 17 users
- Recommended age: 3–14 years
- Frame: Galvanised and powder-coated steel posts, 80 x 80 mm profile (stainless steel version available)
- Climbing walls: Anti-slip, waterproof HPL panels
- Climbing holds: Polyester-resin composite with mineral fillers
- Platforms: Anti-slip, waterproof HPL
- Rope ladders: Steel-core rope with synthetic rungs
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Ropes: Steel-core rope with polypropylene braid; plastic, stainless steel or aluminium connectors
- Bars & fittings: Stainless steel
- Fixings: Stainless steel or cap-covered screws; rubber or polypropylene post caps
- Foundations: Concrete footings 60–80 cm deep on level ground
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: Free-fall height is 2.25 m, so impact-absorbing surfacing is needed across the impact area: a synthetic surface tested to EN 1177 for a critical fall height of at least 2.25 m, or 400 mm of loose-fill bark, woodchip or sand. We'll specify and quote the right surface for your site.
- Morti ref.: MSP1716JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
