Rope Tunnel Bridge – Crawl-Through Trim Trail Element
Crawl-through rope tunnel on stainless steel rims, strung between galvanised steel posts. Trim trail element for ages 4–14, BS EN 1176 certified.
Overview
A suspended rope tunnel on stainless steel rims, strung between angled steel posts. Children crawl through the moving tunnel from one end to the other, building core strength, balance, coordination and spatial awareness. It adds a different kind of challenge to a trim trail, working well as a crossing between rope, timber or balance elements on school playgrounds and in parks. Galvanised, powder-coated steel posts carry a steel-core rope tunnel with plastic, stainless steel or aluminium connectors and calibrated stainless steel chains, built for busy public sites. The tunnel is designed for one user at a time. Certified to BS EN 1176-1 for ages 4–14.
- Product type: Suspended rope tunnel, trim trail element
- Functions: Crawling, balance, core strength, coordination
- Dimensions (L x W x H): 3.36 x 0.60 x 2.23 m
- Safety zone: 6.36 x 3.60 m (21.0 m²)
- Free-fall height: 1.15 m
- User capacity: 1
- Users: Recommended age 4–14
- Frame: 100 x 100 mm steel posts, hot-dip galvanised and powder-coated (or powder-galvanised and powder-coated)
- Tunnel: Steel-core rope in polypropylene braid on stainless steel rims
- Connectors: Plastic, stainless steel or aluminium
- Chains & fixings: Calibrated stainless steel chains; stainless or capped screws; polypropylene end caps
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: EN 1177 impact-absorbing surfacing across the impact area, rated to at least 1.15 m
- Morti ref.: MSP1603JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
