Climbing Cube with Climbing Wall, Rope Net & Fireman's Pole
Compact steel climbing cube with climbing wall, rope net, rope ladder, climbing ropes and fireman's pole for 12 users aged 3–14. BS EN 1176.
Overview
Six climbing activities around one compact steel cube, so up to 12 children can climb at once from every side. There's a climbing wall with moulded hand holds, a rope net, a rope ladder and hanging climbing ropes to scale, overhead bars for pulling up, and a stainless steel fireman's pole for the quick way down. It builds grip, strength and coordination in a small footprint, ideal for KS1 and KS2 playgrounds, parks and housing development play areas with limited space. Galvanised, powder-coated 80 mm steel posts, an HPL wall panel and steel-core rope; certified to BS EN 1176-1.
- Product type: Compact steel climbing cube with six activities
- Play activities: Climbing wall (HPL wall with moulded hand holds); Rope net (vertical net on one face); Rope ladder (ladder with synthetic rungs); Climbing ropes (hanging ropes to climb hand over hand); Fireman's pole (stainless steel pole for the quick way down); Overhead bars (steel bars for hanging and pulling up)
- Dimensions (L x W x H): 1.99 x 1.55 x 1.93 m
- Safety zone: 4.99 x 4.55 m (20.1 m²)
- Free-fall height: 1.80 m
- User capacity: 12 users
- Recommended age: 3–14 years
- Frame: Galvanised and powder-coated steel posts, 80 x 80 mm profile (stainless steel version available)
- Climbing walls: Anti-slip, waterproof HPL panels
- Climbing holds: HDPE hand-hold elements
- Fireman's pole: Stainless steel
- Rope ladders: Steel-core rope with synthetic rungs
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Ropes: Steel-core rope with polypropylene braid; plastic, stainless steel or aluminium connectors
- Bars & fittings: Stainless steel
- Fixings: Stainless steel or cap-covered screws; rubber or polypropylene post caps
- Foundations: Concrete footings 60–80 cm deep on level ground
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: Free-fall height is 1.80 m, so impact-absorbing surfacing is needed across the impact area: a synthetic surface tested to EN 1177 for a critical fall height of at least 1.80 m, or 300 mm of loose-fill bark, woodchip or sand. We'll specify and quote the right surface for your site.
- Morti ref.: MSP1778JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
.webp)
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
