Multi-Activity Timber Climbing Frame with Tube Slide, Nets & Climbing Walls
Timber climbing frame for 17 users aged 3–14 with climbing walls, rope net, climbing bars, spinners and a stainless steel tube slide. BS EN 1176.
Overview
A compact timber tower packed with ways to climb up and slide down. Children tackle climbing walls with holds, a rope net and ladder-style steel climbing bars to reach the raised platforms, play with the spinning panels at the top, then come down the stainless steel tube slide. The mix of routes builds strength, coordination and confidence for up to 17 users, making it a strong all-rounder for KS1 and KS2 playgrounds, parks and housing development play areas. Laminated, impregnated pine posts on galvanised anchors, HPL and HDPE panels and steel-core rope; certified to BS EN 1176-1.
- Product type: Timber climbing tower with tube slide, nets and climbing walls
- Play activities: Climbing walls (panels with HDPE climbing holds); Rope net (net climb up to the platform); Climbing bars (ladder-style steel bars on the sides); Spinning panels (colourful spinners at the top); Tube slide (stainless steel tube slide down); Platforms (raised decks with side panels)
- Dimensions (L x W x H): 3.06 x 2.30 x 2.30 m
- Safety zone: 6.52 x 5.79 m (29.9 m²)
- Free-fall height: 2.20 m
- User capacity: 17 users
- Recommended age: 3–14 years
- Posts: Laminated, impregnated and double-coated knot-free pine, 90 x 90 mm, with polypropylene top caps
- Post anchors: Hot-dip galvanised steel feet keep the timber clear of the ground to prevent rot
- Platforms & walls: Anti-slip, waterproof plywood or HPL on galvanised, powder-coated steel frames
- Panels: Weather-resistant HDPE or HPL side and moving panels
- Climbing holds: Weather-resistant HDPE
- Tube slide: Stainless steel
- Rope ladders: Steel-core rope with synthetic rungs
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Ropes: Steel-core rope with polypropylene braid; plastic, stainless steel or aluminium connectors
- Bars & fittings: Stainless steel
- Fixings: Cap-covered or stainless steel screws; polypropylene post caps
- Foundations: Concrete footings 60–80 cm deep on level ground
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: Free-fall height is 2.20 m, so impact-absorbing surfacing is needed across the impact area: a synthetic surface tested to EN 1177 for a critical fall height of at least 2.20 m, or 400 mm of loose-fill bark, woodchip or sand. We'll specify and quote the right surface for your site.
- Morti ref.: MSP1439JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
