Large Timber Adventure Multi-Play Unit with Bridges, Nets & Climbing Walls
Large timber multi-play unit for 51 users aged 3–14: climbing walls, rope and plank bridges, nets, fireman's pole and roofed towers. BS EN 1176.
Overview
A full adventure playground in one structure, with 13 activities spread across linked towers and platforms. Children climb in via climbing walls, rope nets, a rope ladder and a spiral step climber, cross between towers on a rope bridge and a wobbly plank bridge, and come back down by the fireman's pole. Roofed towers, a chalkboard and play panels add space for rest and imaginative play. Built for up to 51 users, it suits large primary school playgrounds, parks and community play areas. Laminated, impregnated pine posts on galvanised anchors, HPL and HDPE panels and steel-core rope; certified to BS EN 1176-1.
- Product type: Linked timber towers with bridges, nets and climbing walls
- Play activities: Climbing walls (panels with HDPE climbing holds); Climbing nets (rope net climbs between levels); Rope bridge (net-sided bridge between towers); Plank bridge (wobbly bridge that tests balance); Spiral step climber (stepping pods around a post); Rope ladder (ladder with synthetic rungs); Fireman's pole (stainless steel pole down from the tower); Chalkboard & panels (drawing board and play panels)
- Dimensions (L x W x H): 6.27 x 3.19 x 3.40 m
- Safety zone: 9.27 x 7.06 m (56.2 m²)
- Free-fall height: 2.20 m
- User capacity: 51 users
- Recommended age: 3–14 years
- Posts: Laminated, impregnated and double-coated knot-free pine, 90 x 90 mm, with polypropylene top caps
- Post anchors: Hot-dip galvanised steel feet keep the timber clear of the ground to prevent rot
- Platforms & walls: Anti-slip, waterproof plywood or HPL on galvanised, powder-coated steel frames
- Roofs & panels: Weather-resistant HDPE or HPL; drawing board in plywood or HPL
- Climbing holds: Weather-resistant HDPE
- Fireman's pole: Stainless steel
- Rope ladders: Steel-core rope with synthetic rungs
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Ropes: Steel-core rope with polypropylene braid; plastic, stainless steel or aluminium connectors
- Bars & fittings: Stainless steel
- Fixings: Cap-covered or stainless steel screws; polypropylene post caps
- Foundations: Concrete footings 60–80 cm deep on level ground
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: Free-fall height is 2.20 m, so impact-absorbing surfacing is needed across the impact area: a synthetic surface tested to EN 1177 for a critical fall height of at least 2.20 m, or 400 mm of loose-fill bark, woodchip or sand. We'll specify and quote the right surface for your site.
- Morti ref.: MSP1413JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
