Compact Climbing Frame with Climbing Wall & Rope Net
Space-saving steel climbing frame with a climbing wall and rope net for 8 users aged 3–14. Small footprint, BS EN 1176. For schools and parks.
Overview
A space-saving climbing frame that fits five activity points into a footprint of just 1.57 x 0.81 m. Children choose between a vertical climbing wall with moulded hand holds on one face and a rope net on the other, with overhead steel bars across the top, so up to eight users can climb at once. It's an easy way to add climbing to smaller playgrounds, early years and KS1 settings, pocket parks and housing development play areas. Built from galvanised, powder-coated 80 mm steel with an HPL wall panel and steel-core rope, and certified to BS EN 1176-1.
- Product type: Space-saving steel climbing frame with climbing wall and rope net
- Play activities: Climbing wall (HPL wall with moulded hand holds); Rope net (vertical net on the opposite face); Overhead bars (steel bars linking the routes)
- Dimensions (L x W x H): 1.57 x 0.81 x 1.93 m
- Safety zone: 4.57 x 3.81 m (15.5 m²)
- Free-fall height: 1.80 m
- User capacity: 8 users
- Recommended age: 3–14 years
- Frame: Galvanised and powder-coated steel posts, 80 x 80 mm profile (stainless steel version available)
- Climbing walls: Anti-slip, waterproof HPL panels
- Climbing holds: HDPE hand-hold elements
- Rope ladders: Steel-core rope with synthetic rungs
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Ropes: Steel-core rope with polypropylene braid; plastic, stainless steel or aluminium connectors
- Bars & fittings: Stainless steel
- Fixings: Stainless steel or cap-covered screws; rubber or polypropylene post caps
- Foundations: Concrete footings 60–80 cm deep on level ground
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: Free-fall height is 1.80 m, so impact-absorbing surfacing is needed across the impact area: a synthetic surface tested to EN 1177 for a critical fall height of at least 1.80 m, or 300 mm of loose-fill bark, woodchip or sand. We'll specify and quote the right surface for your site.
- Morti ref.: MSP1777JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
