Triple Rope Climbing Trail – Rope Bridge, Climbing Net & Climbing Ropes
Rope trail with a wavy rope bridge, climbing net and climbing ropes. Up to 14 users aged 4–14. BS EN 1176 certified for schools, councils and parks.
Overview
Three rope challenges in one angled run: a wavy rope bridge, a vertical climbing net and a row of climbing ropes. Children cross, climb and pull their way along the trail, building balance, grip, coordination and upper-body strength. Up to 14 children can use it at once, and the open frame keeps clear sightlines for supervision. The 7.25 m run works on its own or as part of a longer trim trail in a school playground or park. Galvanised, powder-coated steel posts carry steel-core rope with synthetic rungs and calibrated stainless steel chains. Certified to BS EN 1176-1 for ages 4–14.
- Product type: Three-part rope climbing trail
- Functions: Climbing, balance, pull-up and grip, passage, upper-body strength, coordination
- Dimensions (L x W x H): 7.25 x 1.80 x 2.25 m
- Safety zone: 10.65 x 5.60 m (41.9 m²)
- Free-fall height: 2.0 m
- User capacity: 14
- Users: Recommended age 4–14
- Frame: 100 × 100 mm steel posts, hot-dip galvanised and powder-coated (or powder-galvanised and powder-coated)
- Ropes: Steel-core ropes in polypropylene braid with plastic, stainless steel or aluminium connectors
- Rungs: Synthetic
- Chains: Calibrated stainless steel chains to prevent finger entrapment
- Fixings: Stainless steel screws or screws under plastic caps; polypropylene end caps
- Standard: BS EN 1176-1:2017+A1:2023
- Surfacing: EN 1177 impact-absorbing surfacing across the impact area, rated to at least 2.0 m
- Morti ref.: MSP1630JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
